Fuse specification
Model
IT8512A+
IT8512A+
IT8512B+
IT8512C+
IT8512H+
IT8513A+
IT8513C+
IT8514B+
IT8514C+
IT8516C+
After replacement, install the fuse box back to original position, as
shown below.
Copyright © Itech Electronics Co., Ltd.
(220VAC)
T0.5A 250V
T0.5A 250V
T0.5A 250V
T0.5A 250V
T0.5A 250V
T1.25A 250V
T1.25A 250V
T1.25A 250V
T1.25A 250V
T2.5A
250V
Quick Start
Fuse specification
(110VAC)
T1.25A 250V
T1.25A 250V
T1.25A 250V
T1.25A 250V
T1.25A 250V
T2.5A 250V
T2.5A 250V
T2.5A 250V
T2.5A 250V
T5A 250V
13
