I/O Port source current selection
The PA~PD input/output ports have programmable source current functions. Four levels of source
current can be selected by the registers.
IOHR0 Register
Bit
�a�e IOHS31
R/W R/W
POR
Bit 7~6 IOHS31~IOHS30: PA3 source current output selection bit
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
Bit 5~4 IOHS21~IOHS20: PA2 source current output selection bit
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
Bit 3~2 IOHS11~IOHS10: PA1 source current output selection bit
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
IOHS01~IOHS00: PA0 source current output selection bit
Bit 1~0
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
IOHR1 Register
Bit
�a�e IOHS�1
R/W R/W
POR
Bit 7~6 IOHS71~IOHS70: PA7 source current output selection bit
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
Bit 5~4 IOHS61~IOHS60: PA6 source current output selection bit
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
IOHS51~IOHS50: PA5 source current output selection bit
Bit 3~2
00: Full source current output
01: 10/22 full source current output
10: 7/22 full source current output
11: 4/22 full source current output
