A cyclic LCD waveform includes two frames, known as Frame 0 and Frame 1 which is selected by
the FRAME bit in the SLCDC0 register. The following offers a functional explanation.
To select Frame 0 clear the FRAME bit to 0.
In frame 0, the COM signal output can have a value of V
The SEG signal can have a value of V
In frame 1, the COM signal output can have a value of V
The SEG signal can have a value of V
The SCOM0~SCOMn waveform is controlled by the application program using the FRAME bit,
and the corresponding I/O data register for the respective SCOM pin to determine whether the
SCOM0~SCOMn output has a value of either V
is controlled in a similar way using the FRAME bit and the corresponding I/O data register for the
respective SSEG pin to determine whether the SSEG0~SSEGn output has a value of either V
or Vbias.
Rev. 1.21
A/D Flash MCU with EEPROM
f r a m e 0
0
0 0 0 1
0 0 0
1 1
0 0 0
0
1
0 0 0 0
1
0 1 1 0 0
1 1 0 1 1
1/3 Bias LCD Waveform
