MICRO-EPSILON optoCONTROL 1202 Instruction Manual page 12

Model
LED-indication
Protection class
Shock
Vibration
Operating temperature
Storage temperature
Output
Digital input
Power supply
Sensitivity adjustment
Laser adjustment
The quoted technical data apply for a displacement light source to receiver about 300 mm and a temperature
of 20 °C (+68 °F) after a warm-up time of 30 minutes.
1) Display resolution of the software ≤ 10 µm
2) Valid for ΔT≤5°C and ambient light 5000 lx. For stable measurement shadowing of the receiver is
3) Is only valid with the adaption of the THD threshold and the laser performance as well as the execution of
4) Laser class 1: IEC 60825-1: 2008-05
5) Shadowing from ambient daylight increases the signal stability
optoCONTROL 1202
Analog
Digital
IN0
IN1
advisable. Smooth video AVG 64 values.
an calibration; 20 mm target-receiver distance; 250 mm transmitter-receiver distance
optoCONTROL 1202-75
LED red (+): Measuring value > upper tolerance threshold
LED green: Measuring value lies within tolerance threshold
LED red (-): Measuring value < lower tolerance threshold
LED yellow: multifunction
electronics: IP 54, optics: IP 67
15 g / 6 ms
15 g / 10 Hz...1 kHz
-10 to +50 °C (+14 to +122 °F)
-20 to +85 °C (-4 to +185 °F)
0 ...+10V (scalable)
OUT0, OUT1, OUT2: pnp-bright-switching/npn-dark-switching or
pnp-dark-switching/npn-bright-switching, adjustable under Windows,
max. 100 mA, short-circuit proof
external trigger, input voltage +Ub/0 V with protective circuit
teach/Reset, input voltage +Ub/0 V with protective circuit
+15 VDC ... + 30 VDC, typ. 200 mA
using Windows via PC (parameterization software included)
adjustable using Windows via PC
optoCONTROL 1202-100
