5.
The measurement system optoCONTROL 1202 is an optical system for measurements with µm accuracy.
Make sure it is handled carefully when installing and operating.
5.1
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted.
> Inaccurate, erroneous measuring values
Housing
ODC1202-75-T
ODC1202-75-R
ODC1202-100-T
ODC1202-100-R
optoCONTROL 1202

Installation and Mounting

Sensor Mounting

Mount the transmitter and receiver above every the three through holes (dia. 4.5) or above every the two
tapped blind holes M5.
Push through
length
mm
30
30
30
30
Bolt connection
Screw Washer
ISO 4762 - A2 ISO 7089 - A2
M4 A4.3
M4 A4.3
M4 A4.3
M4 A4.3
Tightening torque
per screw
µ = 0.12
Nm
2
2
2
2
Page 14
