Reset Function, In1; Teach Function, In1 - MICRO-EPSILON optoCONTROL 1202 Instruction Manual

6.6
When a HIGH-pulse of less than 750 ms duration is applied at input IN1, see
performed at the receiver. This resets the current maximum and minimum values. If the receiver detects a
RESET pulse, the yellow LED at the housing of the receiver blinks shortly one time, see
6.7
When a HIGH-pulse of more than 1.5 s duration is applied at Input IN1, see
performed at the receiver. If the receiver detects a TEACH pulse, the yellow LED at the housing of the receiver
blinks shortly three times.
Fig. 14 Pulse duration at digital input IN1 decides about Reset- or Teach function
Fig. 15 Yellow multifunction LED on the receiver
optoCONTROL 1202

RESET Function, IN1

TEACH Function, IN1

T < 0.75 s
R
+U
B
Reset
0 V
On: Visualization operating voltage
1 x shortly blinking: Reset- max/min function
3 x shortly blinking: Teach function
T > 1.5 s
T
Teach
Time [s]
Fig. 14, the RESET function is
Fig. 15.
Fig. 14, the TEACH function is
