HMC7000 Series I/O Module Guide

Wiring:

For connecting to NPN-type transistor inputs:

Configuration:

Use MAPware-7000 to assign input (X and XW) and configuration (M and MW) memory addresses to the
module. These addresses are created according to the slot location of the module, where nn refers to the slot
number (ex. 01...05):
Function
X0-X15 Inputs
High Speed Counter Option
HSC Input Pin
HSC Reset Input Pin
HSC Configuration Register
HSC Counter Register
(Current Value)
HSC Preset Register
HSC Enable Bit
HSC Reset Bit
HMC7000 Series I/O Module Guide
Connecting to PNP-type transistor inputs:
Register
Xnn000-015 (XWnn00)
HSC Channel 1 HSC Channel 2
X0 X5
X1 X6
MWnn00 MWnn06
MWnn01 MWnn07
MWnn02 MWnn08
MWnn03 MWnn09
MWnn04 MWnn10
Mnn080 Mnn176
Mnn081 Mnn177
8
Access
Rd Only
Rd Only
Rd Only
Rd/Write
Rd/Write
Rd/Write
Rd/Write
Rd/Write
8
