HMC7000 Series I/O Module Guide

Configuration:

Use MAPware-7000 to assign input (X and XW), output (Y and YW), and configuration (M and MW) memory
addresses to the module. These addresses are created according to the slot location of the module, where nn
refers to the slot number (ex. 01...05):
Function
X0-X7 Inputs
Y0-Y7 Outputs
High Speed Counter
Option
HSC Input
HSC Reset Input
HSC Output Flag
HSC Configuration
Register
HSC Counter Register
(Current Value)
HSC Preset Register
HSC Enable Bit
HSC Reset Bit
Reference the table below when configuring each HSC Configuration Register (MWnn00 and MWnn06):
Bits
15-4 Not used
3 0 : Falling Edge
1 : Rising Edge
2, 1, 0 Module Operating Mode :
000 : Normal Operation
010 : Up Counter HSC
HMC7000 Series I/O Module Guide
Xnn000-007 (XWnn00)
Ynn000-007 (YWnn00)
HSC Channel 1
X0 (terminal)
Xnn000 (reg)
X1 (terminal)
Xnn001 (reg)
Y1 (terminal)
Ynn001 (reg)
MWnn00
MWnn01
MWnn02
MWnn03
MWnn04
Mnn080
Mnn081
Function
Register
HSC Channel 2
X5 (terminal)
Xnn005 (reg)
X6 (terminal)
Xnn006 (reg)
Y6 (terminal)
Ynn006 (reg)
MWnn06
MWnn07
MWnn08
MWnn09
MWnn10
Mnn176
Mnn177
