HMC7000 Series I/O Module Guide
Reference the table below when configuring each Input Configuration Register (MWnn00-MWnn03):
Input Channel
Signal Type
Voltage, 0 to 10V
Voltage, 0 to 5V
Voltage, -10 to +10V
Voltage, 0 to 50mV
Voltage, 0 to 100mV
Current, 4 to 20mA
Current, 0 to 20mA
RTC and Thermocouple
1
RTD, PT100, alpha1
1
RTD, PT100, alpha2
RTD, PT1000
2
Thermocouple, Type J
Thermocouple, Type K
Notes:
1. alpha1= 0.00385 Ω/Ω/°C, alpha2=0.003926 Ω/Ω/°C
2. 15-minute module warm-up time recommended
Reference the table below when configuring each Output Configuration Register (MWnn04-MWnn05):
Output Channel
Signal Type
Voltage, 0 to 10V
Voltage, 0 to 5V
Current, 4 to 20mA
Current, 0 to 20mA
HMC7000 Series I/O Module Guide
Value
1
6
18
5
4
2
3
For °C
7 19
8 20
9 21
14 26
2
15 27
Value
2
1
5
6
Value
-
-
-
-
-
-
-
For °F
72
