HMC7000 Series I/O Module Guide

HMC7-MO-01 (12 Relay Output Module)

This module is a digital output module for the HMC7000 Series models.
It has twelve relay outputs.

Specifications:

Power
Approvals
Digital Outputs
Turn ON Time
Turn OFF Time
Output capacity
Connection method
General
Operating Temperature
Operating Humidity
Mechanical Dimension (LxWxH)
Input Power Supply
Input Voltage
Input Current
HMC7000 Series I/O Module Guide
3.9 VDC from HMC7000 base
CE, UL
12 relay outputs
10 msec
5 msec
2A per contact up to 230VAC
2A per contact up to 30VDC
Removable terminals (3.81 mm pitch)
0 to 55°C
10% to 90% (non condensing)
3.11x1.18x1.42 inches [79x30x36mm]
24VDC (required even when using AC loads)
150mA maximum
