- Page 1 USER MANUAL MAPLE MODULAR PLC Digital IO Modules IO-SD3200I • IO-SD0032PI • IO-SD1616PI • IO-SD0808R • IO-SD0016R • IO-SD0032PPWM •...
-
Page 2: Table Of Contents
Contents Module List ............7 General Specifications..........8 Technical Specifications .......... 9 Wiring ..............10 Input/Output Type ..........14 Appearance and Dimensions ......... 15 Product Warranty ..........19 - 2 -... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from MAPLE SYSTEMS Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for wiring of Digital Input/Output Module ( Caution) Select a cable considering ambient temperature and allowable current AWG 22 (0.3 mm ) or more is recommended. If the wiring is too close to a heat-generating device or directly contacted with oil for long periods of time it may cause a short circuit, breakdown or malfunction.
-
Page 7: Module List
Digital IO Module List Category Model Name I/O Points Detail DI 32 points, DC 24 V, Sink/Source Input Module IO-SD3200I DI-32 (Terminal Block Type) DO 32 points, DC 24 V, TR Source IO-SD0032PI DO-32 (Terminal Block Type) Output Module IO-SD0016R... -
Page 8: General Specifications
General Specifications Items Specification Standards Ambient Temp. -10℃–65℃ Storage -25℃–80℃ Temp. Ambient 5–95% RH, Not Condensed Humidity Storage 5–95% RH, Not Condensed Humidity For Discontinuous Vibration Frequency Acceleration Amplitude Times 5 ≤ f < 9 Hz 3.5 mm X, Y, Z Each direction, 10 times 9 ≤... -
Page 9: Technical Specifications
Technical Specifications Items DC Input Relay Output TR Output Rated I/O Voltage DC 24 V AC 220 V / DC 24 V DC 12V / 24 V 1 point 2 A 1 point 0.2 A Rated I/O Current COM 5 A COM 2 A On Voltage/Current DC 19 V/3 mA... -
Page 10: Wiring
Wiring IO-SD0016R - 10 -... - Page 11 Wiring IO-SD0808R - 11 -...
- Page 12 Wiring IO-SD3200I IO-SD0032PI IO-SD1616PI - 12 -...
- Page 13 Wiring IO-SD0032PPWM PWM Output Points * All the other points can be used as a normal output points. - 13 -...
-
Page 14: Input/Output Type
Input / Output Type Sink Type Source Type - 14 -... -
Page 15: Appearance And Dimensions
Appearance ▶IO-SD0032PPWM ▶IO-SD0808R ▶IO-SD0016R - 15 -... - Page 16 Appearance ▶IO-SD0032PI ▶IO-SD3200I ▶IO-SD1616PI - 16 -...
- Page 17 Dimensions ▶ MODULES (IO-SD3200I, IO-SD0032PI, IO-SD0032PPWM) (Unit: mm) - 17 -...
- Page 18 Dimensions ▶ MODULES (IO-SD1616PI, IO-SD0808R, IO-SD0016R) (Unit: mm) - 18 -...
-
Page 19: Product Warranty
Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - 19 -... - Page 20 MAPLE SYSTEMS INC. Everett, WA 98204 Web: www.maplesystems.com...
