Hmc7-Mo-02 (16 Sinking Output Module); Specifications - Maple Systems HMC7000 Series Manual

HMC7000 Series I/O Module Guide

HMC7-MO-02 (16 Sinking Output Module)

This module is a digital output module for the HMC7000 Series models.
It has 16 sinking (NPN) outputs.

Specifications:

Power
Approvals
Digital Outputs
Turn ON Time
Turn OFF Time
Output Capacity
Rated load
Total output capacity
Connection method
General
Operating Temperature
Operating Humidity
Mechanical Dimension (LxWxH)
Input Power Supply
Input Voltage
Input Current
HMC7000 Series I/O Module Guide
3.9 VDC from HMC7000 base
CE, UL
16 sinking (NPN) outputs
10 msec
10 msec
500mA per output maximum
500mA @ 24VDC
4A @ 24VDC
Removable terminals (3.81 mm pitch)
0 to 55°C
10% to 90% (non condensing)
3.11x1.18x1.42 inches [79x30x36mm]
24VDC
850mA maximum
