HMC7000 Series I/O Module Guide

Specifications:

Power
Approvals
Digital Inputs
Rated input voltage
Rated input current
Input impedance
Minimum ON voltage
Maximum OFF voltage
Turn ON Time
Turn OFF Time
Isolation
Connection method
High Speed Channels
No. of inputs
Maximum Input Frequency
Maximum Input Count
Digital Outputs
Output Capacity (PNP)
Output Capacity (relay)
Rated load
High Speed Channels
No. of Outputs
General
Operating Temperature
Operating Humidity
Mechanical Dimension (LxWxH)
Input Power Supply
Input Voltage
Input Current
HMC7000 Series I/O Module Guide
3.9 VDC from HMC7000 base
CE, UL
8 bidirectional inputs
24 VDC
Up to 5mA
4.9K ohms
15 VDC
5 VDC
10 msec
10 msec
Optically isolated from internal circuit
Removable terminals (3.81 mm pitch)
4 channels (X0 and X5, X2 and X7)
25 KHz
4,294,967,295 (32-bit)
6 relay, 2 sourcing outputs (PNP-type)
500mA per output maximum
2A per contact, 6A per common
500mA @ 24VDC (250 mA PWM)
2 channels (Y2 and Y4)
0 to 55°C
10% to 90% (non condensing)
3.11x1.18x1.42 inches [79x30x36mm]
24VDC
4A maximum
