Wiring - Maple Systems IO-SA0400 User Manual

Wiring of RTD (IO-SA0400)
Channel
CH 1
CH 2
CH 3
CH 4
24 V External
Wiring of TC (IO-SA0400T)
Channel
CH 1
CH 2
CH 3
CH 4
AGND
24 V External
A Terminal
Terminal 1
Terminal 4
Terminal 7
Terminal 10
Connection: bottom of module
+ Terminal
Terminal 1
Terminal 3
Terminal 5
Terminal 7
Connection: bottom of module
- 13 -
B Terminal
Terminal 2
Terminal 5
Terminal 8
Terminal 11
Terminal 9
b Terminal
Terminal 3
Terminal 6
Terminal 9
Terminal 12
- Terminal
Terminal 2
Terminal 4
Terminal 6
Terminal 8
