HMC7000 Series I/O Module Guide
Configuration:
Use MAPware-7000 to assign input (XW) and configuration (MW) memory addresses to the module. These
addresses are created according to the slot location of the module, where nn refers to the slot
number (ex. 01...05):
Register
XWnn00
XWnn02
XWnn04
XWnn06
YWnn00
XWnn01
MWnn00
MWnn01
MWnn02
MWnn03
MWnn04
MWnn05
MWnn10
Analog Input Error Register Bit Assignment
15
14
13
12
HMC7000 Series I/O Module Guide
Description
Input Channel 1 Data
Input Channel 2 Data
Input Channel 3 Data
Input Channel 4 Data
Output Channel 1 Data
Output Channel 2 Data
Input Channel 1 Configuration Register
Input Channel 2 Configuration Register
Input Channel 3 Configuration Register
Input Channel 1 Configuration Register
Output Channel 1 Configuration Register
Output Channel 2 Configuration Register
Analog Input Error Register
11
10
09
08
07
06
05
Access
Read Only
Read Only
Read Only
Read Only
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
04
03
02
01
71
00
71
