- Page 1 USER MANUAL MAPLE MODULAR PLC Analog IO Modules IO-SA0400Y • IO-SA0800Y • IO-SA0202Y • IO-SA0004C • IO-SA0004V • - 1 -...
-
Page 2: Table Of Contents
Contents General Specifications ........7 Performance Specifications .......8 Features ............10 Wiring Method..........11 Input Wiring ............ 13 Output Wiring ..........16 Appearance & Dimensions ......18 Product Warranty ......... 21 - 2 -... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from MAPLE SYSTEMS Inc. is prohibited. Safety symbols are classified into two categories: “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown on PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for wiring of Analog Module ( Caution) Cables for module input signals should be separate from AC power to prevent the influence of surge or induction noise occurring from AC. Select a cable considering ambient temperature and allowable current AWG16–28 recommended.
-
Page 7: General Specifications
General Specifications Items Specification Standards Op. Temp. -10℃–60℃ St. Temp. -25℃–80℃ Op. Hum. 5–95% RH, Non-condensing St. Hum. 5–95% RH, Non-condensing In case of Intermittent Vibration Frequency Acceleration Amplitude Times 5 ≤ f < 9 Hz 3.5 mm 10 times in X,Y,Z 9 ≤... -
Page 8: Performance Specifications
Analog Output (Specifications) Items IO-SA0202Y IO-SA0004V IO-SA0004C Analog Output Point 2 points 4 points Voltage: 0–5 V, 1–5 V, 0–10 V, 0–10 V. -10–10 V -10–10V Analog Output 4–20 mA Current: 0–20 mA, (switch mode) 4–20 mA Switch OFF: 0–10V Setting by Output Setting Method Switch ON: -10–10V... - Page 9 Analog Input (Specifications) Items IO-SA0400Y IO-SA0800Y IO-SA0202Y Analog Input Point 4 points 8 points 2 points 10 V (Input resistor: 1 – – – – Voltage: 0 5 V, 1 5 V, 0 10 V, -10 MΩ, 20 MΩ) Analog Input –...
-
Page 10: Features
Features of Analog Module 1. IO-SA0400Y is an analog input module which has 4ch voltage/current Input. IO-SA0800Y is an analog input module which has 8ch voltage/current input. IO-SA0004V is an analog output module which has 4ch voltage output (-10–10 V, 0–... -
Page 11: Wiring Method
Wiring Method ▶ Prior to wiring Analog Input to Terminal, double check terminal (+) and (-). ▶ IO-SA0400Y Voltage Input Channel + Terminal - Terminal CH 1 Terminal 1 Terminal 3 CH 2 Terminal 4 Terminal 6 CH 3 Terminal 7... - Page 12 Wiring Method ▶ IO-SA0202Y Voltage Input/Output Channel + Terminal - Terminal Terminal 1 Terminal 3 AD 1 Ch Input AD 2 Ch Terminal 4 Terminal 6 DA 1 Ch Terminal 7 Terminal 9 Output Terminal 10 Terminal 12 DA 2 Ch Ext.
-
Page 13: Input Wiring
Input Wiring ▶ IO-SA0800Y (Voltage/Current set by the switch) - 13 -... - Page 14 Input Wiring ▶ IO-SA0400Y Current Input ▶ IO-SA0400Y Voltage Input - 14 -...
- Page 15 Input Wiring ▶ IO-SA0202Y Current Input ▶ IO-SA0202Y Voltage Input - 15 -...
-
Page 16: Output Wiring
Output Wiring ▶ IO-SA0202Y Voltage Output ▶ IO-SA0202Y Current Output - 16 -... - Page 17 Output Wiring ▶ IO-SA0004C Current Output ▶ IO-SA0004V Voltage Output - 17 -...
-
Page 18: Appearance & Dimensions
Appearance ▶IO-SA0400Y ▶IO-SA0202Y ▶IO-SA0004V ▶IO-SA0004C - 18 -... - Page 19 Appearance ▶IO-SA0800Y - 19 -...
- Page 20 Dimensions ▶ All analog modules are the same size. - 20 -...
-
Page 21: Product Warranty
Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - 21 -... - Page 22 MEMO - 22 -...
- Page 23 MEMO - 23 -...
- Page 24 MAPLE SYSTEMS INC. 808 134th St SW #120 Everett, WA 98204 Phone +1 425-745-3229 Web: www.maplesystems.com - 24 -...
