13.5
For analysis purposes,
the data transmitted via the Profibus under the actual value parameters.
The parameters are situated in the "Actual values\Actual values frequency in-
verter" menu of the VPlus program and can only be viewed with the latter.
In these parameters, the data transmitted via the Profibus are displayed in a
processed and comprehensible form. The contents of the process data channel with
control word, reference value etc. are permanently updated. As the communication
channel has the contents zero in idling and transmission is very fast, the contents of
the communication channel are stored on the device side and displayed in the actual
value parameters with every transmission.
The displayed content of the communication channel does not correspond to the cur-
rent state, but the last transmission.
Note:
08/08
08/08

Actual value display of Profibus data

DP-Master OUT
The use of the VPlus program with simultaneous use of the Profibus-DP
communication module CM-PDPV1 is only possible with the KP232 serial
adapter on the slot of the KP500 control unit.
Only the usage of the PKW object is displayed for parameter access.
When using the V1-Channel for parameter access there is no information
displayed.
CM-PDPV1
CM-PDPV1
DP-Master IN
281 and 284 are displayed in
