The various control functions and methods and the hardware of the frequency inverter
contain functions which continuously monitor the application. As a supplement to the
messages documented in these operating instructions, the following failure keys are
activated by the EM-IO-03 expansion module.
Alongside the fault messages stated, there are further fault messages, however they
are only used for internal purposes and are not listed here. If you receive fault mes-
sages which are not listed here, please contact us by phone.
06/05
06/05

Annex

Error messages

F14 02 Reference value signal on analog input EM-S1INA faulty, check signal.
30 Speed sensor signal 2 is faulty, check connections
31 One track of the speed sensor signal 2 is missing, check connections.
32 Direction of rotation of speed sensor 2 wrong, check connections.
33 Speed sensor 2, divisions marks wrong, check speed sensor
34 Division marks of speed sensor signal 2 too low, check speed sensor.
35 Division marks of speed sensor signal 2 too high, check speed sensor.
F21 nn Fault report to system bus master in fault in system bus slave
nn = Node ID of slave (hex)
F22 00 Communication fault, system bus, timeout SYNC telegram
01 Communication fault, system bus, timeout RxPDO1
02 Communication fault, system bus, timeout RxPDO2
03 Communication fault, system bus, timeout RxPDO3
10 Communication fault, system bus, bus OFF
