15.3
;=============================================================================
; Profibus Device Database of HMS Industrial Networks.
;
; Model Anybus-CC PROFIBUS DP-V1
; CM-PDPV1 at Bonfiglioli Vectron GmbH
; Description: Anybus-CC PROFIBUS DP-V1 slave
; Language: English
; Author: HMS Industrial Networks / Bonfiglioli Vectron GmbH
; WWW: www.anybus.com / www.vectron.net
;
; Revision log:
; 09.08.2007 Bonfiglioli Vectron GmbH
; Model_name changed to ACTIVE-DPV1
; Ident_Number changed to 0x0B2C (PNO)
; Slave family changed to 1 "Drive"
; I/O related keywords changed to Bonfiglioli settings
; Unit_Diag_Area=32-39 changed to Bonfiglioli settings
; C1/2_Max_Data_Len ,C1/2_Response_Timeout changed to Bonfiglioli settings
; Definition of modules changed to Bomfiglioli settings
;
;=============================================================================
#Profibus_DP
GSD_Revision = 5
; Device identification
Vendor_Name = "HMS Industrial Networks"
Model_Name = "ACTIVE-DPV1"
Revision = "2.05"
Ident_Number = 0x0B2C
Protocol_Ident = 0
Station_Type = 0
FMS_supp = 0
Slave_Family = 1
Hardware_Release = "Version 2.03"
Software_Release = "Version 2.03"
; Supported hardware features
Redundancy = 0
Repeater_Ctrl_Sig = 2
24V_Pins = 0
Implementation_Type = "NP30"
; Supported DP features
Freeze_Mode_supp = 1
Sync_Mode_supp = 1
Auto_Baud_supp = 1
Set_Slave_Add_supp = 1
Fail_Safe = 1
; Supported baudrates
9.6_supp = 1
19.2_supp = 1
45.45_supp = 1
93.75_supp = 1
187.5_supp = 1
500_supp = 1
1.5M_supp = 1
3M_supp = 1
6M_supp = 1
12M_supp = 1
; Maximum responder time for supported baudrates
MaxTsdr_9.6 = 15
MaxTsdr_19.2 = 15
MaxTsdr_45.45 = 15
MaxTsdr_93.75 = 15
MaxTsdr_187.5 = 15
MaxTsdr_500 = 15
MaxTsdr_1.5M = 25
MaxTsdr_3M = 50
MaxTsdr_6M = 100
MaxTsdr_12M = 200
08/08
08/08
GSD File – BV__0B2C.GSD
; DP protocol
; Slave device
; FMS not supported
; Drive
; not supported
; TTL
; not connected
; supported
; supported
; supported
; supported
; supported
CM-PDPV1
CM-PDPV1
55
55
