General Safety And Application Information; General Information; Proper Use - BONFIGLIOLI Vectron ACTIVE CUBE Manual

1
This documentation has been produced with the greatest of care and extensively and
repeatedly checked. For reasons of clarity, not all the detailed information on all types
of the product and also not every imaginable case of installation, operation or main-
tenance has been taken into account. If you require further information or if specific
problems which are not dealt with extensively enough in the documentation exist, you
can request the necessary information via the local representation of the company
BONFIGLIOLI.
We would also point out that the contents of this documentation are not part of a
previous or existing agreement, assurance or legal relationship and are not intended
to amend the same. All obligations of the manufacturer result from the underlying
purchase contract, which also contains the complete and solely valid warranty regula-
tion. These contractual warranty provisions are neither extended nor limited by the
production of this documentation.
The manufacturer reserves the right to correct or amend the contents and the product
information as well as omissions without prior notification and assumes no kind of
liability for damage, injuries or expenditure to be put down to the aforementioned
reasons.
1.1
Warning! BONFIGLIOLI VECTRON frequency inverters have high voltage levels dur-
1.2
Warning! The frequency inverters are electrical drive components intended for in-
08/08
08/08

General safety and application information

General information

ing operation, depending on their protection class, drive moving parts and
have hot surfaces.
In the event of inadmissible removal of the necessary covers, improper
use, wrong installation or operation, there is the risk of serious damage to
persons or property.
To avoid any damage, only qualified staff may carry out the transport,
installation, setup or maintenance work required. Comply with the stan-
dards EN 50178, IEC 60364 (Cenelec HD 384 or DIN VDE 0100), IEC
60664-1 (Cenelec HD 625 or VDE 0110-1), BGV A2 (VBG 4) and national
provisions. Qualified persons within the meaning of this principal safety
information are people acquainted with the installation, fitting, commis-
sioning and operating of frequency inverters and the possible hazards and
in possession of qualifications matching their activities.

Proper use

stallation in industrial plants or machines. Commissioning and start of
intended operation are not allowed until it has been established that the
machine corresponds to the provisions of the EC machine directive
98/37/EEC and EN 60204. According to the CE sign, the frequency inver-
ters additionally fulfill the requirements of the low-voltage directive
2006/95/EC and standards EN 50178/DIN VDE 0160 and EN 61800-2.
Responsibility for compliance with the EMC directive 89/336/EEC is with
the user. Frequency inverters are available in a limited way and as com-
ponents exclusively intended for professional use within the meaning of
the EN 61000-3-2.
With the issue of the UL according to UL508c, the requirements of the
CSA Standard C22.2-No. 14-95 have also been fulfilled.
The technical data and the information on connection and ambient condi-
tions the rating plate and the documentation be complied with. The in-
structions must be read and fully understood before starting work on the
device.
