Word data type – Torque
For the torque specification, the calculation must be done in the device-internal scal-
ing. The scaling for a torque value is identical to the specification of the reference
current (see Current). If the machine is operated with nominal flux, a reference tor-
que corresponds to a reference current.
Note:
Long data type
The Long data type can be used for the frequency and position variables.
Frequencies use the internal notation of the inverter (xxx Hz / 4000 Hz) * 2
Examples:
Position information depends on the settings of the motion control system. (Refer to
the manual "Positioning".)
x/y = 3/4, 5/6, ... 17/18
08/08
08/08
The equation stated for current (torque) applies for operation with no-
minal flux. If a machine is operated in the field weakening area, this is to
be considered in the specification values.
If the current or torque variables are used, please take into account the
device-specific scaling.
50.00 Hz (50.00 / 4000.00) * 2
-80.00 Hz (-80.00 / 4000.00) * 2
data content
OUT/IN-PZDx/y Long 0xnnnnmmmm
CM-PDPV1
31
= 0x01999999
31
= 0xFD70A3D8
Long data type
data content
hexadecimal decimal
Application-
specific
CM-PDPV1
31
.
logical
interpretation
Application-
specific
31
31
