The baud rate is not explicitly set. The Profibus component supports the Auto_Baud
function and independently determines the baud rate set on the bus.
The maximum line length recommended by the PNO correlates to the Baud rate.
6
A maximum of 125 slave frequency inverters can be operated on the Profibus-DP.
Each frequency inverter is assigned a node ID for its unambiguous identification; this
ID may only exist once in the system. The setting of the node ID is carried out via
parameter
No.
391 Profibus Node-ID
Note:
12
12

Baud rate setting/line length

Profibus-DP interface
Baud rate/kBaud
9.6
19.2
45.45
93.75
187.5
500
1500
3000
6000
12000

Setting the station address

Profibus Node-ID
Parameter
Description
Profibus Node-ID
CM-PDPV1
max. line length/m
1200
1200
1200
1200
1000
400
200
100
100
100
391.
Min.
-1
391= -1 means Profibus function switched off.
CM-PDPV1
Setting
Max. Fact. sett.
126 -1
