The following diagrams show the display for a configuration setting with PPO2. The
PPO2 includes the communication PKW channel for parameter access and 6 PZD ob-
jects with default settings for In-PZD objects.
Parameter
= C: a nnnn I: iiii 00 V: wwwwww cccc rrrr xxxx xxxx xxxx xxxx
C: a
C: nnnn
I: iiii
V: ww..w ww..w = parameter value
cccc
rrrr
xxxx
xxxx
xxxx
xxxx
Parameter
= C: a nnnn I: iiii 00 V: wwwwww cccc ssss xxxx xxxx xxxx xxxx
C: a
C: nnnn
I: iiii
V: ww..w
cccc
ssss
xxxx
xxxx
xxxx
xxxx
50
50
DP-Master OUT
281
= request identification hexadecimal
a
nnnn = parameter number
iiii = index
PZD1 = control word
PZD2 = reference value
PZD3 user defined
PZD4 user defined
PZD5 user defined
PZD6 user defined
DP-Master IN
284
= reply identification hexadecimal
a
nnnn = parameter number decimal
iiii = index
ww..w = parameter value
PZD1 = state word
PZD2 = actual value
PZD3 = abs. current
PZD4 = active current
PZD5 = Warning
PZD6 = Fault
CM-PDPV1
CM-PDPV1
Actual value
Meaning
decimal
hexadecimal
decimal (with sign in front)
hexadecimal
hexadecimal, relative to
0x4000 = 100% of the reference value
hexadecimal
hexadecimal
hexadecimal
hexadecimal
Actual value
Meaning
hexadecimal
decimal (with sign in front)
hexadecimal
hexadecimal, relative to
0x4000 = 100% of the reference value
hexadecimal, relative to 0x4000 =
100% of the rated motor current
hexadecimal, relative to 0x4000 =
100% of the rated motor current
hexadecimal (bit-coded)
hexadecimal
