BONFIGLIOLI Vectron ACTIVE CUBE Manual page 48

Ready
Operation enabled
Fault
(*) without considering bits 7 to bit 15
Note:
The Warning bit "Bit No. 7" can be set at any time. It indicates a device-internal
warning message. The evaluation of the present warning is carried out by reading out
the warning status with parameter
The Remote bit "Bit No. 9" is set if the operation mode control via remote contacts
Local/Remote
(
then can the frequency inverter be controlled via the control word.
The bit Reference value reached "Bit No. 10" is set whenever the specified refer-
ence value has been reached. In the special case of power failure regulation, the bit is
also set if the power failure regulation has reached the frequency 0 Hz (see operating
instructions). For "Reference value reached" there is a hysteresis (tolerance range),
which can be set via parameter
tions).
The bit Limit value active "Bit No. 11" indicates that an internal limit is active. This
can, for example, be the present current limit, the torque limit or the over-voltage
limit. All the functions lead to the reference value being quit or not reached.
The bit Warning 2 "Bit No. 15" indicates a warning which leads to a fault switch-off
of the frequency inverter within a short period of time. This bit is set if there is a
warning for motor temperature, heat sink/inside temperature, Ixt monitoring or mains
phase failure.
Note:
Signal sources are:
- S1IND ... S6IND,
- MFI1D,
- EM-S1IND ... EM-S3IND
46
46
State HEX (*)
0x23
0x27
0x08
The occurrence of a fault leads to a switch-over to the "Fault" state.
A fault can only be acknowledged 15 seconds after its occurrence, as a
blocking time is active internally.
412 = 2) has been set and the hardware release is available. Only
With the use of remote contacts the signal sources* are taken over from
Control Word
the 410. Signals at the hardware contacts (terminals) are
not evaluated by the standard operation modes (e.g. 71 for S2IND).
For the evaluation of terminal signals special operation modes are availa-
ble. They are denoted with the additional term "(Hardware)" and num-
bered from 526 to 546.
Exception: The controller release via the hardware contacts STOA (termin-
al X210A.3) and STOB (terminal X210B.2) must be set and Bit 0 "Inverter
controlword
Release" of the
It is not possible to release the controller only via software.
CM-PDPV1
CM-PDPV1
State word
Bit 6 Bit 5 Bit 3
0 1 0
0 1 0
0 x 1
Warnings
270.
max. Control deviation
must be set.
Bit 2 Bit 1 Bit 0
0 1 1
1 1 1
0 0 0
549 (see operating instruc-
08/08
08/08
