Profibus Output Sources (Out-Pzd X) - BONFIGLIOLI Vectron ACTIVE CUBE Manual

13.3.2
The table below lists the available output sources of the PZD Out objects. The content
of the sources depends on the application. For the different data types the equivalent
sources must be connected to the inverter input parameters.
Note:
no. of configured
PZD objects
2 Out-PZD3 Boolean
Out-PZD4 Boolean
3 Out-PZD5 Boolean
Out-PZD6 Boolean
4 Out-PZD7 Boolean
Out-PZD8 Boolean
5 Out-PZD9 Boolean
Out-PZD10 Boolean
6 Out-PZD11 Boolean
Out-PZD12 Boolean
7 Out-PZD13 Boolean
Out-PZD14 Boolean
8 Out-PZD15 Boolean
Out-PZD16 Boolean
9 Out-PZD17 Boolean
Out-PZD18 Boolean
Note:
32
32

Profibus output sources (OUT-PZD x)

• The availability of Out sources depends on the number of configured
PZD objects.
• Every configured PZD object consists of either two Boolean, two
word or one long output object.
• One PZD out object can be used for one data type only (depending
on the application requirements).
• The first configured PZD object (mandatory) represents the PZD1/2
with fixed contents and functions.
Boolean Sources
name src-no.
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
• Every source can be connected to an inverter input parameter with
the same data type. This method is the same as used with System-
bus receive objects.
Boolean sources are representatives for Boolean objects
•
• Word sources are representatives for current or torque objects
Long sources are representatives for frequency or position objects
•
CM-PDPV1
CM-PDPV1
Word Sources
name src-no.
Out-PZD3 Word 656
Out-PZD4 Word 657
Out-PZD5 Word 658
Out-PZD6 Word 659
Out-PZD7 Word 660
Out-PZD8 Word 661
Out-PZD9 Word 662
Out-PZD10 Word 663
Out-PZD11 Word 664
Out-PZD12 Word 665
Out-PZD13 Word 666
Out-PZD14 Word 667
Out-PZD15 Word 668
Out-PZD16 Word 669
Out-PZD17 Word 670
Out-PZD18 Word 671
Long Sources
name src-no.
Out-PZD3_4 Long 672
Out-PZD5_6 Long 673
Out-PZD7_8 Long 674
Out-PZD9_10 Long 675
Out-PZD11_12 Long 676
Out-PZD13_14 Long 677
Out-PZD15_16 Long 678
Out-PZD17_18 Long 679
