Note:
Current scaling:
Reference value
The possible range = ±200% = +32768 to -32768 = 0x8000 to 0x7FFF
For the internal scaling, the data set change-over capable parameter
371 is used as a reference.
No.
371 Rated current
34
34
The displayed "PDP active current" depends on the control system. In
field-orientation, the torque-forming current is displayed, in applications
with a v/f characteristic control, the active current, which is also a meas-
ure for the torque.
The "PDP absolute current" (r.m.s. current) is always positive. Active cur-
rent and torque-forming current have a sign prefixed.
Positive currents = motor
Negative currents = generator operation.
Standardization
Binary
14
+ 100 % + 2
Parameter
Description
CM-PDPV1
Decimal
16384
Min.
0.01 · I
CM-PDPV1
Hexadecimal
0x4000
Rated current
Setting
Max. Fact. Sett.
10 · I I
FIN FIN FIN
