Status Parameters; Error Behaviour - BONFIGLIOLI Vectron ACTIVE CUBE Manual

8
The Profibus module CM-PDPV1 has two actual value parameters which display the
current status of the module itself as well as that of the controlling software in the
inverter.
Status Control
inverter.
Status Fieldbus Module
The
during operation.
Wait_Process_PDP
Wait_Process2_PDP
Process_Active_PDP
WAIT_PROCESS
PROCESS_ACTIVE
These parameters can show other messages that are usually not of interest. These
messages are of interest for Bonfiglioli Vectron support in the case of problems and
trouble shooting.
9
In the event of Profibus errors (e. g. Profibus OFF), the behaviour of the inverter can
be set with
No.
393 Profibus Error Reaction
Operation mode 393
0 - No Reaction
1 - Error
2 - Coast to Stop
3 - Quick Stop
Note:
14
14

Status Parameters

365 displays the software state of the the controlling software in the
366 displays the module state.
Status Control
365 and
Status Control
365
Status Fieldbus Module

Error Behaviour

Profibus Error Reaction
Parameter
Description
The operation modes "2 - Coast to Stop" and "3 - Quick Stop" are only
available when
CM-PDPV1
Status Fieldbus Module
Description
Waiting for connection to Profibus master
Waiting for reconnection to Profibus master after
connection loss
Connection to Profibus master established, Data-
Exchange with Profibus master running
366 Description
Waiting for connection to Profibus master
Connection to Profibus master established,
Data-Exchange with Profibus master running
393.
Min.
Inverter remains in the current state.
Inverter enters error state.
Inverter power stages are switched off and drive stops in
free run.
Drive is decelerated with quick stop ramps.
Local/Remote
412 is set to "1 - Control via Statemachine".
CM-PDPV1
366 show the following states
Setting
Max. Fact. Sett.
0 3
Function
1
