Default Jumper and Switch Settings

Figure 1-3 calls out the major features on the ZC702 board. See the ZC702 Evaluation Board
for the Zynq-7000 XC7Z020 All Programmable SoC User Guide (UG850)
detailed information about the ZC702 board.
X-Ref Target - Figure 1-3
Quad SPI Flash Memory (1 Gb)
SD Card Interface Connector
System Clock, 200 MHz,
2.5V LVDS
Configuration Mode Select Switch
12V Power Connector
I2C Bus Switch
Power On/Off Slide Switch
CAN Bus Transceiver
HDMI Controller,
HDMI Video Connector
USB JTAG
Module with Integrated
USB Micro-B Connector
Default factory settings of jumpers and switches on the ZC702 board are highlighted in
1-4. Default switch and jumper settings are listed in
Figure
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
2
/ -inch, 8 mm C-mount lens
3
I2C Programmable User
Clock 3.3V LVDS
FMC1 LPC Xilinx XADC
Connector
10/100/1000 MHz
Ethernet PHY,
RJ45 with Magnetics
Ethernet Status
LEDs
Figure 1-3: Feature Callout for the ZC702 Board
www.xilinx.com
Default Jumper and Switch Settings
User Pushbuttons
Active High
FMC2 LPC
Header Connector
USB 2.0 ULPI 2x6 and 1x6
Transceiver, PMOD I/O Header
USB Micro-B
Connector
USB-to-UART Bridge, 2x6 Male Header
USB Mini-B Connector Pins I/O Driven from
I2C Expander U80
Table 1-1
[Ref 4] for more
8 User LEDs
User 2-Pole DIP Switch
Zynq-7000 AP SoC
PMBus Connector
(Bottom of board)
Power Management System
(Bottom and Top of Board)
FPGA PROG Pushbutton
DDR3 Component
Memory (1 GB)
I2C Real-time Clock (RTC)
RGMII Ethernet
PHY Oscillator,
25,000 MHz
UG926_c1_03_111913
and Table 1-2.
