Getting Started with the Base Targeted
Reference Design
Introduction
This section provides step by step instructions for bringing up the board and running the
video Targeted Reference Design (TRD). In this design, the Zynq-7000 AP SoC performs
real-time processing of a 1080p60 video stream—either in Processing System (PS) software
or Programmable Logic (PL) hardware accelerator. The video processing path is
user-selectable through a graphical user interface (GUI) running on Linux in the Zynq-7000
AP SoC PS. The GUI also displays detailed information about system usage statistics and
system performance.
Figure 3-1
shows the system block diagram for Zynq-7000 AP SoC Base TRD.
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
