Chapter 2: ZC702 Evaluation Kit Built-In Self-Test

Hardware BIST Board Setup

This section describes the hardware setup and use of the terminal program for running the
BIST application. It contains step-by-step instructions for board bring-up.
ZC702 Evaluation Board Setup
The default jumper and switch settings of the ZC702 board are shown in
Table 1-1, and Table
1. Set the SW16 switch as shown in
the right and position 4 is switched to the left for the BIST to boot from Quad SPI device
and run the system demonstration utility.
X-Ref Target - Figure 2-1
Figure 2-1: Settings for the Mode Switch to Boot from Quad SPI Mode
16
1-2.
Figure
www.xilinx.com
2-1, where position 1, 2, 3, and 5 are switched to
UG926_c2_01_061212
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Figure 1-4,
