Chapter 3: Getting Started with the Base Targeted Reference Design
X-Ref Target - Figure 3-1
Linux User Space
Command Line Application
Linux Kernel
Kernel Libraries and Utilities
Processing
System
Figure 3-1: Zynq-7000 AP SoC ZC702 and ZVIK Base TRD System Block Diagram
The Base TRD showcases various features and capabilities of the Zynq Z-7020 AP SoC for the
embedded domain in a single package. The Base TRD consists of two processing elements:
The Zynq-7000 AP SoC processing system (PS) and an interconnect logic-based video
accelerator. The AP SoC allows the user to implement a specific functionality either as a
software program running on the Zynq-7000 AP SoC PS or as a hardware design inside the
programmable logic (PL). The Base TRD demonstrates how the user can seamlessly switch
between a software or a hardware implementation, contributing to ease of use. The TRD also
demonstrates the value of offloading computation-intensive tasks onto PL, thereby freeing
the CPU resources to be available for user-specific applications.
The ZC702 evaluation kit and ZVIK come with an SD card loaded with binaries that enable
the user to run the video demonstration and software application. It also includes the
binaries necessary to configure and boot the Zynq-7000 AP SoC board.
The screen captures in this document are conceptual representations of their subjects and
Note:
provide general information only.
26
Qt-Based Multithreaded Application
DDR Memory Controller
AMBA Switches
APU
AMBA Switches
www.xilinx.com
Device Drivers
Programmable
Logic
Display Controller
Video Processing
(Sobel Filter)
Video Test Pattern
Generator
S_AXI3_HP 64 bit
M_AXI3_GP 32 bit
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Video
Output
(Optional)
Video Input
with
Zynq-7000
Video and
Imaging Kit
UG926_c3_01_061213
