Using the AMS101 Evaluation Card

Introduction

Each Xilinx Zynq-7000 AP SoC features two 1 MSPS, 12-bit, analog-to-digital converters
(ADCs) built into the device for everything from simple analog monitoring to more signal
processing-intensive tasks like linearization, calibration, over-sampling, and filtering. The
ZC702 evaluation kit includes the hardware and software to evaluate this ADC feature and to
determine its usefulness in the user's end system.
For evaluation of Xilinx Agile Mixed Signal (AMS) capability, the following items in the kit are
needed:
• Access to the ZC702 XADC header
• AMS101 evaluation card (see
• Design and software files, which can be downloaded from the web
• Zynq-7000 AP SoC design programming files
• USB-UART drivers from Silicon Labs
• Blank
SD MMC
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Figure 4-1)
card
