2. Type these commands at the Linux command prompt into the host PC based terminal:
zynq> run_sobel.sh -cmd -res 1920x1080
The menu-based video application demonstration starts as shown in
X-Ref Target - Figure 3-9
Exercise different options by entering the use case number displayed in
Enter your choice: on the terminal.
Table 3-2: Zynq-7000 AP SoC Base TRD Video Demonstration Use Cases
Use Case
1
2
3
Additional ZVIK Options
4
5
6
Video source control modes are explained as follows:
• TPG interference
The input video is generated by the TPG IP implemented in the PL.
°
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Running the UART Menu-Based Demonstration Application
Figure 3-9: Command Line Based UI Menu
Video Source Control
TPG interference
TPG interference
TPG interference
External video
External video
External video
www.xilinx.com
Figure
UG926_c3_09_111913
Sobel Filter Control
Sobel OFF
Sobel - SW
Sobel - HW
Sobel OFF
Sobel - SW
Sobel - HW
Send Feedback
3-9.
against
Table 3-2
