Zynq-7000 AP SoC Video and Imaging Kit Contents

The ZVIK contains all of the items included in the ZC702 evaluation kit plus the following
items. For more information on the HDMI input/output FMC module and ON Semiconductor
image sensor, refer to the Avnet product page
• HDMI input/output FPGA mezzanine card (FMC) module
• ON Semiconductor VITA 2000 Color Image Sensor module
• Standard interchangeable
• Infrared (IR) cut filter
• Camera tripod
• Lens holder
• Cables
Second HDMI cable
°
LCEDI image sensor cable
°
For reference design files, documents, and board source files, go to the
SoC Video and Imaging Kit documentation page.

Key Features of the ZVIK

Key features of the additional components of the Zynq-7000 AP SoC Video and Imaging kit
include:
• HDMI input/output FMC module
HDMI input
°
HDMI output
°
Video clock synthesizer
°
Interface for ON Semiconductor VITA image sensor module
°
• ON Semiconductor VITA 2000 color image sensor module
Supports up to WXGA resolution: 1920 (H) x 1200 (V) format
°
92 frames per second (fps) at full resolution
°
4.8 μ m x 4.8 μ m pixel size
°
Pipelined and triggered global shutter, rolling shutter
°
10
[Ref 3].
2
/ -inch 8 mm C-mount lens
3
2
/ -inch optical format
3
