3. Wait for the ZC702 board to be configured and booted with Linux. The XILINX ZYNQ
banner appears on the display monitor after approximately two minutes as shown in
Figure
3-5.
X-Ref Target - Figure 3-5
4. The Qt-based video demonstration application starts. The GUI application shows up at
the bottom of the screen (see
X-Ref Target - Figure 3-6
ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Figure 3-5: Zynq Banner
Figure
Figure 3-6: Qt-Based GUI to Control the Video Pipeline
www.xilinx.com
Running the Qt-Based GUI Application Demonstration
3-6).
UG926_c3_05_111012
UG926_c3_06_102813
Send Feedback
33
