Danfoss FC 300 Programming Manual page 44

2. How to Programme
1-36 Iron Loss Resistance (Rfe)
Range:
Size related [1 - 10.000 Ω]
2
1-37 d-axis Inductance (Ld)
Range:
0.0mH [0.0 - 1000.0 mH]
1-39 Motor Poles
Option:
* Depends on motor type Value 2 - 100 poles
[4]
Poles
2
4
6
The table shows the number of poles for normal speed ranges of various motor types. Define motors designed for other frequencies separately. The
motor pole value is always an even number, because it refers to the total number of poles, not pairs of poles. The frequency converter creates the initial
setting of par. 1-39 based on par. 1-23
1-40 Back EMF at 1000 RPM
Range:
*
500 V [10 - 9000 V]
1-41 Motor Angle Offset
Range:
*
0 [-32768 - 32768]
2.4.5. 1-5* Load Indep. Setting
Parameters for setting the load-independent motor settings.
44
Function:
Enter the equivalent iron loss resistance (R
The R value cannot be found by performing an AMA.
Fe
The R value is especially important in torque control applications. If R
Fe
setting.
Function:
Enter the value of the d-axis inductance. Obtain the value from the permanent magnet motor data sheet.
This parameter is only active when par. 1-10
nent Magnet Motor).
This parameter is available for FC 302 only.
Function:
Enter the number of motor poles.
~n @ 50 Hz
n
2700 - 2880
1350 - 1450
700 - 960
Motor Frequency and par. 1-25
Function:
Set the nominal back EMF for the motor when running at 1000 RPM. This parameter is only active when par.
Motor construction
1-10
This parameter is available for FC 302 only.
NB!
When using PM motors, it is recommended to use brake resistors.
Function:
Enter the correct offset angle between the PM motor and the index position (single-turn) of the attached encoder
or resolver. The value range of 0 - 32768 corresponds to 0 - 2 * pi (radians). To obtain the offset angle value:
After frequency converter start-up apply DC-hold and enter the value of par. 16-20
rameter.
This parameter is only active when par. 1-10
Magnet Motor).
MG.33.M3.02 - VLT
) value to compensate for iron loss in the motor.
Fe
Motor construction
~n @60 Hz
n
3250 - 3460
1625 - 1730
840 - 1153
Motor Nominal Speed .
PM motor
is set to [1] (Permanent Magnet Motor).
Motor construction
®
is a registered Danfoss trademark
FC 300 Programming Guide
is unknown, leave par. 1-36 on default
Fe
PM, non-salient SPM
has the value [1] (Perma-
Motor Angle
into this pa-
PM, non-salient SPM
is set to [1] (Permanent
