2. How to Programme
0-13 Readout: Linked Set-ups
Array [5]
*
0 [0 - 255]
2
Index
0
1
2
3
4
Table 2.1: Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Edit Set-ups / Channe
Range:
*
0 [0 - FFF.FFF.FFF]
2.3.4. 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
NB!
Please refer to parameters 0-37, 0-38 and 0-39 for information on how to write display texts
[0] None
[953] Profibus Warning Word
[1005] Readout Transmit Error
Counter
[1006] Readout Receive Error
Counter
[1007] Readout Bus Off Coun-
ter
[1013] Warning Parameter
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
30
View a list of all the set-ups linked by means of par. 0-12
for each parameter set-up. The parameter value displayed for each index represents which setups are linked to
that parameter setup.
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
Function:
Edit Set-up
View the setting of par. 0-11
is displayed in hex, as it is in the LCP, each number represents one channel.
Numbers 1-4 represent a set-up number; 'F' means factory setting; and 'A' means active set-up. The channels
are, from right to left: LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means that the FC bus selected Set-up 2 in par. 0-11, the LCP selected Set-
up 1 and all others used the active set-up.
Select a variable for display in line 1, left position.
No display value selected.
Present control word
Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected unit.
Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
Present status word.
One or more warnings in a Hex code.
®
