Danfoss FC 300 Programming Manual page 78

2. How to Programme
4-51 Warning Current High
Range:
*
par. 16-37 A [Par. 4-50 - par.
16-37]
2
4-52 Warning Speed Low
Range:
*
0 RPM [0 - par. 4-13]
4-53 Warning Speed High
Range:
*
par. 4-13 RPM [Par. 4-52 - par.
4-13]
4-54 Warning Reference Low
Range:
*
-999999.999 [-999999.999 - par.
4-55]
4-55 Warning Reference High
Range:
*
999999.999 [Par. 4-54 -
999999.999]
4-56 Warning Feedback Low
Range:
*
-999999.999 [-999999.999 - par.
4-57]
4-57 Warning Feedback High
Range:
*
999999.999 [Par. 4-56 -
999999.999]
4-58 Missing Motor Phase Function
Displays an alarm in the event of a missing motor phase.
[0] Off
*
On
[1]
This parameter cannot be adjusted while the motor is running.
2.7.5. 4-6* Speed Bypass
Define the Speed Bypass areas for the ramps.
78
Function:
Enter the I value. When the motor current exceeds this limit, the display reads
HIGH
outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output
01 or 02 (FC 302 only). Refer to the drawing in this section.
Function:
Enter the n value. When the motor speed exceeds this limit, the display reads
LOW
can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output 01 or 02
(FC 302 only).
Function:
Enter the n value. When the motor speed exceeds this limit, the display reads
HIGH
can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output 01 or 02
(FC 302 only). Programme the upper signal limit of the motor speed, n
the frequency converter. Refer to the drawing in this section.
Function:
Enter the lower reference limit. When the actual reference falls below this limit, the display indicates
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on
relay output 01 or 02 (FC 302 only).
Function:
Enter the upper reference limit. When the actual reference exceeds this limit, the display reads Ref High. The
signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay
output 01 or 02 (FC 302 only).
Function:
Enter the lower feedback limit. When the feedback falls below this limit, the display reads Feedb Low. The signal
outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output
01 or 02 (FC 302 only).
Function:
Enter the upper feedback limit. When the feedback exceeds this limit, the display reads Feedb High. The signal
outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output
01 or 02 (FC 302 only).
Select [Off] for no missing motor phase alarm. However the [On] setting is strongly recommended to avoid
motor damage.
Select [On] to display an alarm in the event of a missing motor phase.
®
MG.33.M3.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
Current High
. The signal
Speed Low
. The signal outputs
Speed High . The signal outputs
, within the normal working range of
HIGH
Ref Low .
