[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
2
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-03 Reset SLC
Option:
*
Do not reset SLC
[0]
[1] Reset SLC
2.14.3. 13-1* Comparators
Comparators are used for comparing continuous variables (i.e. output frequency, output current, analog input etc.) to fixed preset values. In addition,
there are digital values that will be compared to fixed time values. See explanation in par. 13-10. Comparators are evaluated once in each scan interval.
Use the result (TRUE or FALSE) directly. All parameters in this parameter group are array parameters with index 0 to 5. Select index 0 to programme
Comparator 0, select index 1 to programme Comparator 1, and so on.
13-10 Comparator Operand
Array [6]
Choice [1] to [31] are variables which will be compared based on their values. Choice [50] to [186] are digital values (TRUE/FALSE) where the comparison
is based on the amount of time during which they are set to TRUE or FALSE, respectively. See par. 13-11.
Select the variable to be monitored by the comparator.
* DISABLED
[0]
[1] Reference
[2] Feedback
130
Select the boolean (TRUE or FALSE) input to activate Smart Logic Control.
For descriptions [0] - [61], see 13-01
SL Time-out 3
[70] Smart logic controller timer 3 is timed out.
SL Time-out 4 [71] Smart logic controller timer 4 is timed out.
SL Time-out 5 [72] Smart logic controller timer 5 is timed out.
SL- Time-out 6 [73] Smart logic controller timer 6 is timed out.
SL Time-out 7
[74] Smart logic controller timer 7 is timed out.
Function:
Retains programmed settings in all group 13 parameters (13-*).
Resets all group 13 parameters (13-*) to default settings.
DISABLED [0] The comparator is disabled.
Reference
[1] The resulting remote reference (not local) as a percentage.
Feedback [2] In the unit [RPM] or [Hz]
®
