Danfoss VLT AQUA Drive FC 202 Design Manual page 175

Specifications
525–600 V, Enclosure Sizes A, B, and C
Enclosure Power [kW (hp)]
A2 1.1–4.0 (1.5–5)
A3 5.5–7.5 (7.5–10)
A5 1.1–7.5 (1.5–10)
B1 11–18 (15–24)
B2 22–30 (30–40)
B3 11–18.5 (15–25)
B4 22–37 (30–50)
C1 37–55 (50–65)
C2 75–90 (100–125)
C3 45–55 (60–75)
C4 75–90 (100–125)
Table 7.21 52–-600 V, Enclosure Sizes A, B, and C
MG20N622
Design Guide
Recommended Recommended
fuse size maximum fuse
gG-10
gG-10 (5.5)
gG-16 (7.5)
gG-10 (0.75–5.5)
gG-16 (7.5)
gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-63 (37) gG-160 (37–45)
gG-100 (45) aR-250 (55)
aR-160 (55)
aR-200 (75)
gG-63 (37)
gG-100 (45)
aR-160 (55)
aR-200 (75)
Danfoss A/S © 09/2014 All rights reserved.
Recommended circuit
breaker
Moeller
gG-25 PKZM0-25
gG-32 PKZM0-25
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
gG-63 PKZM4-50
gG-125 NZMB1-A100
NZMB2-A200
aR-250 NZMB2-A250
gG-150 NZMB2-A200
aR-250 NZMB2-A250
Maximum trip level
[A]
25 (82)
25
25
63
100
50
7
100
160
250
150
250
173
7
