Specifications
Type designation
High/normal overload
Typical shaft output [kW]
Typical shaft output at 208 V [hp]
Protection rating IP20/Chassis
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
Output current
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
Continuous kVA at 208 V [kVA]
Maximum input current
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
7 7
Maximum pre-fuses [A]
Additional specifications
Maximum cable cross-section
brake, and load sharing [mm
Maximum cable cross-section
disconnect
2
[mm ] [(AWG)]
Estimated power loss
5)
Efficiency
Table 7.3 Line Power Supply 3x200–240 V AC, P1K1–P3K7
150
®
VLT
1)
6)
2) for line power, motor,
2 ] ([AWG])
2)
for line power
3) at rated maximum load [W] 4)
Danfoss A/S © 09/2014 All rights reserved.
AQUA Drive FC 202
P1K1 P1K5
HO NO HO NO
1.1 1.5
1.5 2
A2 A2
A4/A5 A4/A5
6.6 7.5
9.9 7.3 11.3 8.3
2.38 2.70
5.9 6.8
8.9 6.5 10.2 7.5
20 20
63 82
0.96 0.96
P2K2 P3K0
HO NO HO NO
2.2 3.0
3 4
A2 A3
A4/A5 A5
10.6 12.5
15.9 11.7 18.8 13.8
3.82 4.50
9.5 11.3
14.3 10.5 17.0 12.4
20 32
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
6, 4, 4 (10, 12, 12)
116 155
0.96 0.96
P3K7
HO NO
3.7
5
A3
A5
16.7
25 18.4
6.00
15.0
22.5 16.5
32
185
0.96
MG20N622
