Danfoss VLT AQUA Drive FC 202 Design Manual page 130

Type code and Selection
10% duty cycle, horizontal braking, T2
Adjustable frequency drive data
P
Line
m
power [kW
type (hp)]
0.25
T2
(0.34)
T2 0.37 (0.5)
0.55
6 6
T2
(0.75)
T2 0.75 (1.0)
T2 1.1 (1.5)
T2 1.5 (2)
T2 2.2 (3)
T2 3 (4)
T2 3.7 (5)
T2 5.5 (7.5)
T2 7.5 (10)
T2 11 (15)
T2 15 (20)
T2 25 (18.5)
T2 22 (30)
T2 30 (40)
T2 37 (50)
T2 45 (60)
Table 6.7 T2, Horizontal Braking 10% Duty Cycle, Recommended Brake Resistors
128
VLT
FC 202
R R R
min br,nom rec
[Ω] [Ω] [Ω]
380 691.3 630
380 466.7 410
275 313.7 300
188 230.0 200
130 152.9 145
81.0 110.5 100
58.5 74.1 70
45.0 53.7 48
31.5 39.9 35
22.5 28.7 27
17.7 20.8 18
12.6 14.0 13
8.7 10.2 9.0
5.3 8.2 5.7
5.1 6.9 5.7
3.2 5.0 3.5
3.0 4.1 3.5
2.4 3.3 2.8
Danfoss A/S © 09/2014 All rights reserved.
®
AQUA Drive FC 202
Horizontal braking 10% duty cycle
Brake resistor data
Danfoss part number
Screw
Wire IP54 terminal
P
br,cont.
IP21
[kW (hp)]
0.100
175u3002 -
(0.134)
0.100
175u3004 -
(0.134)
0.100
175u3006 -
(0.134)
0.100
175u3011 -
(0.134)
0.100
175u3016 -
(0.134)
0.100
175u3021 -
(0.134)
0.200
175u3026 -
(0.268)
0.200
175u3031 -
(0.268)
0.300
175u3325 -
(0.402)
0.360
175u3326 175u3477
(0.483)
0.570
175u3327 175u3442
(0.764)
0.680
175u3328 175u3059
(0.912)
1.130
175u3329 175u3068
(1.515)
1.400
175u3330 175u3073
(1.877)
1.700
175u3331 175u3483
(2.279)
2.200
175u3332 175u3080
(2.949)
2.800
175u3333 175u3448
(3.753)
3.200
175u3334 175u3086
(4.289)
Installation
Cable
cross-
Screw Bolt
section
terminal connection
2
[mm
IP65 IP20
(AWG)]
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
- - 1.5 (16)
175u3478 - 1.5 (16)
175u3441 - 1.5 (16)
175u3060 - 1.5 (16)
175u3069 - 2.5 (14)
175u3074 - 4 (12)
175u3484 - 4 (12)
175u3081 - 6 (10)
175u3447 - 10 (8)
175u3087 - 16 (6)
Thermo
relay
[A]
0.4
0.5
0.6
0.7
0.8
0.9
1.6
1.9
2.7
3.5
5.3
6.8
10.5
15
16
24
27
32
