Specifications
38–480 V, Enclosure Sizes A, B, and C
Enclosure
A2
A3
A4
A5
B1
B2
7 7
B3
B4
C1
C2
C3
C4
Table 7.20 380–480 V, Enclosure Sizes A, B, and C
172
Power [kW (hp)] Recommended
fuse size
1.1–4.0 (1.5–5) gG-10 (0.37–3)
gG-16 (4)
5.5–7.5 (7.5–10) gG-16
1.1–4.0 (1.5–5) gG-10 (0.37–3)
gG-16 (4)
1.1–7.5 (1.5–10) gG-10 (0.37–3)
gG-16 (4–7.5)
11–18.5 (15–25) gG-40
22–30 (30–40) gG-50 (18.5)
gG-63 (22)
11–18 (15–24) gG-40
22–37 (30–50) gG-50 (18.5)
gG-63 (22)
gG-80 (30)
37–55 (50–65) gG-80 (30)
gG-100 (37)
gG-160 (45)
75–90 (100–125) aR-200 (55)
aR-250 (75)
45–55 (60–75) gG-100 (37)
gG-160 (45)
75–90 (100–125) aR-200 (55)
aR-250 (75)
Danfoss A/S © 09/2014 All rights reserved.
®
VLT AQUA Drive FC 202
Recommended
maximum fuse
gG-25
gG-32
gG-32
gG-32
gG-80
gG-100
gG-63
gG-125
gG-160
aR-250
gG-150 (37)
gG-160 (45)
aR-250
Recommended circuit Maximum trip level
breaker
Moeller
PKZM0-25
PKZM0-25
PKZM0-25
PKZM0-25
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
[A]
25
25
25
25
63
100
50
100
160
250
150
250
MG20N622
