CHARACTERISTICS:

The HD67839 is a DALI / Ethernet - Converter.
It has the following characteristics:
Up to 64 devices on DALI bus;
Configurator for DALI network/devices;
DALI 1 and DALI 2 supported;
SCI1, SCI2 protocols supported;
Isolation between DALI – Ethernet, Power Supply - Ethernet. Additional isolation Power Supply – DALI for HD67839-B2-N version;
Two-directional information between DALI bus and Ethernet bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need "DALI Console" software on your PC in order to perform the following:
Configure the DALI network;
Setup the DALI devices (groups, scenes, IDs, ...);
Test DALI communication.
You need Compositor SW67839 software on your PC in order to perform the following:
Define the parameter of Ethernet line;
Define the parameter of DALI line;
Update the device.
