NETWORK SETTING:

By pressing the button in the Network view, it is possible
to scan the full DALI network and find all the DALI devices,
the groups set and the scenes configured.
By selecting the single DALI devices found, the single
groups, the single scene or the entire DALI network, it is
possible to manage and test the functioning of the network.
D :
EVICES
The means of the fields for "DEVICE INFO" are:
In the field "Device Type" the type of DALI device is
printed;
In the field "Software
version of the DALI device is printed;
In the fields "Power Range" the Min value, Actual
Value and Max Value of the ADV of the DALI device
is printed;
In the fields "DEVICE
the DALI device is printed;
By clicking on "LOAD
from the DALI device will be read;
By clicking on "SET NEW
new address inside the button is set to the DALI
device;
By clicking on "REMOVE
will be removed from the DALI device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
version" the software
STATUS" the actual status of
VALUES" button, the data
ADDRESS" button, the
ADDRESS" button, the ID
Document code: MN67839_ENG
Figure 11: "Device settings" window
