Dali Scene scanning
This command is used to get the scenes configured into the DALI nodes configured in the network.
Note:
This command must be sent to the UDP port 10000.
REQUEST
Byte 0 Byte 1 Byte 2
Hex 0x44 0x41 0x4C
Text D A
RESPONSE
The converter sends back as response an array of data of 1024 bytes. For each DALI node, 16 bytes are reserved, one for each possible
scene configured. Here's the data mapping of the data array sent:
The bytes reserved for the scenes can have these values:
0-254 = Value set for the selected scene
255 = Scene not configures
Note:
In each group of 16 bytes, the first one is for the Scene 0 and the last one is for Scene 15.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte 3 Byte 4 Byte 5
0x49 0x5F 0x53
L I _ S
Byte
0-15
16-31
32-47
.
.
.
1008-1023
Document code: MN67839_ENG
Byte 6 Byte 7 Byte 8
0x43 0x45 0x4E
C E N
Data
Scenes configured on DALI node 0
Scenes configured on DALI node 1
Scenes configured on DALI node 2
Scenes configured on DALI node 63
INFO: www.adfweb.com
User Manual DALI / Ethernet
Revision 1.001
Byte9
0x3D
=
