SET COMMUNICATION:

This section define the fundamental communication parameters of Ethernet bus.
By Pressing the "Set Communication" button from the main window for SW67839 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The means of the fields for the "Ethernet" section are:
In the field "IP ADDRESS" the IP address of the converter is defined;
In the field "SUBNET Mask" the SubNet Mask is defined;
In the field "GATEWAY" the default gateway of the Ethernet network is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for going out of
the net.
The means of the fields for the "DALI" section are:
In the field "DALI Console
If the field "Switch off DALI on
Ethernet commands is received in the defined
If the option "Disable DALI
disabled. The DALI side is scanned only on Ethernet command;
If the option "Enable DALI
DALI sensors, actuators, exc.).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Port" the UDP port used for Ethernet communication is defined;
TimeOut" is checked, the DALI line is switched off if any
"TimeOut (ms)";
Scan" is checked, the automatic scanning of DALI side is
2" is checked, DALI 2 functions are enabled (normally used with
User Manual DALI / Ethernet
Document code: MN67839_ENG
Figure 3: "Set Communication" window
