Group Setting
This command is used to enable/disable the membership of the DALI nodes inside the group.
REQUEST
The DALI ID can be from 0 to 63 (0x00 to 0x3F). The Group Number can be from 0 to 15.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 0x00
2 0x10
3 0x00
4 0x00
5 0x00
6 0x02
7 0x04
8 Counter (increased for every command) (Hex)
9 DALI ID + 0x80 (Hex)
10 Group Number + 0x60 (Hex) = Enabling
or
Group Number + 0x70 (Hex) = Disabling
11 0x00
