ADV Setting
This command is used to set the ADV for a specific DALI node, for a Group or for the entire DALI network.
REQUEST
The DALI ID can have different value in relation to the ADV to manage:
0 to 63 (0x00 to 0x3F) to manage a single DALI node;
64 to 79 (0x40 to 0x4F) to manage the Groups;
80 (0x50) for broadcast.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 DALI ID + 1 (Hex)
2 0x10
3 0x00
4 0x00
5 0x00
6 0x02
7 0x04
8 Counter (increased for every command) (Hex)
9 DALI ID (Hex)
10 ADV to set (Hex)
11 0x00
