CHARACTERISTICS:

The HD67511-A1 is a CAN / Modbus Master - Converter.
It allows the following characteristics:
Up to 500 CAN frames in reading and 500 CAN frame in writing;
Triple isolation between CAN - Power Supply, CAN - Serial, Power Supply - Serial.
Two-directional information between CAN bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67511 software on your PC in order to perform the following:
Define the parameter of CAN line;
Define the parameter of Modbus line;
Define the CAN frames that the Converter can accept to read the information from the Modbus Slaves;
Define the CAN frames that the Converter can accept to write the information to the Modbus Slaves;
Update the device.
